Home Battery LV 4.6
LV storage module, 4.6 (4.85*) kWh usable
Art-No.
0153414
Manufacturer No.
BAT-05K48M0B-02
Product details
Product information "Home Battery LV 4.6"
Capacity increase from 4.6 to 4.85 kWh via software update from installation date January 01, 2025 or later. Only in combination with Home Hub inverter (SE*K-RWB48).
Compatible with the 3-phase RWS Hybrid-WR (firmware update necessary) and the RWB series.
Additional connection cables, cover and stand base must be selected separately.
The power packs in the Home Battery LV series are compatible with the 3-phase RWS and RWB hybrids. Indefinitely expandable and reliable in any application. With up to 5 storage modules, up to 23.0 kWh of usable capacity can be created. Even if these legs and bases are only mentioned as an option, they provide the often desired safe distance from the ground. They also make it possible to level out any unevenness for a secure stand. A clear practical recommendation from us too.
Product advantages:
• All components from a single source
• Reliable compatibility thanks to uniform manufacturer
• Simple installation of the entire system via SetApp
Product features:
• Battery capacity (usable): 4.6 (4.85*) kWh
• Extension time window: unlimited
• Cascadable: up to 5 storage modules
• Cell chemistry: LFP
• Nominal voltage: 44.8 - 56.5 V
• Protection class: IP65
• Dimensions: 500 x 540 x 240 mm (H x W x D)
• Weight: 54.7 kg
• Cooling: passive
*For new systems from January 01, 2025, an increased usable capacity is released in combination with a SolarEdge SE*K-RWB48 inverter. Retroactive release before this date is not possible.
Caution
| Dangerous goods description | LITHIUM ION BATTERIES |
|---|---|
| Dangerous goods Weight (net) (kg) | 54.700 |
| Dangerous goods class | 9 |
| Dangerous goods transportation category | 2 |
| UN No. | 3480 |
| Dangerous goods packaging type | 4G |
| Classification code | M4 |
| Tunnel restriction code | (E) |
Technical details
| Protection degree | IP65 |
|---|---|
| Capacity extendable later | yes without restriction |
| Min. temperature ambient (°C) | -10 |
| Usable capacity (kWh) | 4.60 |
| Battery cell chemistry | LFP |
| Dangerous goods description | LITHIUM ION BATTERIES |
|---|---|
| Dangerous goods Weight (net) (kg) | 54.700 |
| Dangerous goods class | 9 |
| Dangerous goods transportation category | 2 |
| UN No. | 3480 |
| Dangerous goods packaging type | 4G |
| Manufacturer | SolarEdge |
| Manufacturer item name | BAT-05K48 |
| Intrastat country of origin | China |
| Intrastat product number (HS-code) | 85076000 |
| Classification code | M4 |
| Tunnel restriction code | (E) |
| Length incl. packaging (cm) | 74.00 |
|---|---|
| Width incl. packaging (cm) | 60.00 |
| Height incl. packaging (cm) | 34.00 |
| Weight incl. packaging (Kg) | 58.000 |
| Amount per Pallet | 12 |
| Amount Pal. p. Cont. | 33 |
| Amount p. Cont. | 396 |
| Pal. dim. LxBxH (mm) | 1200x800x2184 |
| Pack. material | cardboard box |
| Length without packaging (mm) | 500.00 |
|---|---|
| Width without packaging (mm) | 540.00 |
| Height without packaging (mm) | 240.00 |
| Weight without packaging (kg) | 54.700 |
| Warranty provider | SolarEdge |
|---|---|
| Product warranty (yr) | 10 |
| Standard product warranty (yr) | 10 |
