T-BAT H 5.8 MASTER PACK V2.1
High-voltage lithium-ion-battery
Art. no.
8252800
Manufacturer No.
1020030064
Product details
Product information "T-BAT H 5.8 MASTER PACK V2.1"
CAUTION:
Hazardous material according to UN 3480 / Transport hazard class 9 / Packing Group II
When connecting the SolaX T-BAT H 5.8 Battery, make sure to observe the voltage range of the inverter.
Therefore, for X-1 hybrid devices, at least 1 Master battery and a maximum of 2 Slave batteries must be connected.
For X-3 hybrid devices, at least 1 Master battery and at least 1 slave battery must be connected. A maximum of 3 slave batteries can be connected.
**The V1T-BAT H 5.8 is not compatible with the V2 T-BAT H 5.8**
Nominal capacity (kWh): 5.8
Usable capacity (kWh): 5.1
Standard Power (kW): 2.8
Max. Power (kW): 4.0
Nominal Voltage (V): 115.2
Max. Charging Current (A): 35
Max. Discharging Current (A): 35
Technical details
| Nominal voltage DC (V) | 115.20 |
|---|---|
| Min. temperature ambient (°C) | 5 |
| Usable capacity (kWh) | 5.10 |
| Cell chemistry | LFP |
| Battery voltage | High Voltage |
| Battery cell chemistry | LFP |
| Protection degree | IP55 |
| Max. output current charging (A) | 35.00 |
| Max. output current discharging (A) | 35.00 |
| Intrastat country of origin | China |
|---|---|
| Hazardous goods transportation category | 2 |
| Manufacturer | SolaX Power |
| Hazardous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Hazardous goods Weight (net) (kg) | 72.500 |
| Intrastat product number (HS-code) | 85076000 |
| Hazardous goods class | 9 |
| Hazardous goods packaging type | 4G |
| UN No. | 3480 |
| Manufacturer item name | T-BAT H 5.8 |
| Pal. weight (kg) | 688.00 |
|---|---|
| Weight incl. packaging (Kg) | 81.500 |
| Pal. dim. LxBxH (mm) | 1360x810x2010 |
| Height incl. packaging (cm) | 86.90 |
| Length incl. packaging (cm) | 67.10 |
| Amount p. Cont. | 180 |
| Amount per Pallet | 8 |
| Width incl. packaging (cm) | 40.30 |
| Height without packaging (mm) | 708.00 |
|---|---|
| Weight without packaging (kg) | 72.500 |
| Length without packaging (mm) | 474.00 |
| Width without packaging (mm) | 193.00 |
| Warranty provider | SolaX Power |
|---|---|
| Product warranty (yr) | 10 |
