PLENTICORE PLUS 7.0 G2
Hybrid inverter Kostal PLENTICORE plus 7.0 G2
Art. no.
8252313
Manufacturer No.
10535116
Product details
Product information "PLENTICORE PLUS 7.0 G2"
***With battery input with optional activation (Krannich item number for the activation voucher: 8210045)***
***Only released with the following optimizers:
- Maxim Integrated
- Tigo TS4-A-O m***
- Smart performance
- Smart connected
- Easy to install
- 10-year warranty after registration in the KOSTAL Solar online shop
- Charging power depending on battery voltage. Maximum charging current: 13A
Technical details
| Topology | transformerless |
|---|---|
| MPP min. voltage range input (V) | 290.00 |
| Decibel | 39 |
| Surge protection DC | no |
| Max. AC power (kVA) | 7.00 |
| Min. voltage range input (V) | 120 |
| Max. efficiency (%) | 97.20 |
| Interface 2 | W-Lan |
| Backup system light | no |
| Protection degree | IP65 |
| Display | with display |
| Start input voltage (V) | 150 |
| Backup system full | no |
| Max. output current (A) | 11.23 |
| Arc Fault Circuit Interrupter | no |
| Number of independent MPPT (pcs) | 3 |
| European efficiency (%) | 96.50 |
| Max. input voltage DC (V) | 1000.00 |
| Max. input current per MPPT (A). | 13 |
| Interface 1 | Ethernet |
| Battery connection | AC/DC |
| Step-Up converter | yes |
| Max. short circuit current (A) total | 48.75 |
| Surge protection AC | no |
| Min. temperature ambient (°C) | -20 |
| Max. input current DC (A) total | 39.00 |
| Battery voltage | High Voltage |
| Degree of protection IP | IP65 |
| Max. generator power DC (kWp) | 10.50 |
| MPP max. voltage range input (V) | 720.00 |
| Integrated DC switch | yes |
| Offgrid usable | no |
| Total number of string inputs | 3 |
| Contact ripple control receiver | yes |
| Contact for self-consumption optimization (e.g. for heat pump) | 4 |
| Charging current (A) | 13.00 |
| Shadow management | yes |
| Charging voltage (V) | 120-650 |
| DC connector type | SUNCLIX |
| AC nominal power (kW) | 7.00 |
| Max. short circuit current per MPPT (A) | 16,25 |
| Intrastat country of origin | Germany |
|---|---|
| Manufacturer item name | PLENTICORE plus G2 7.0 |
| Intrastat product number (HS-code) | 85044085 |
| Manufacturer | Kostal |
| Width incl. packaging (cm) | 48.50 |
|---|---|
| Weight incl. packaging (Kg) | 19.860 |
| Height incl. packaging (cm) | 29.00 |
| Pal. dim. LxBxH (mm) | 1300x800x1200 |
| Pack. material | cardboard box |
| Length incl. packaging (cm) | 65.00 |
| Pal. weight (kg) | 224.00 |
| Amount per Pallet | 10 |
| Length without packaging (mm) | 563.00 |
|---|---|
| Width without packaging (mm) | 405.00 |
| Height without packaging (mm) | 233.00 |
| Weight without packaging (kg) | 17.860 |
| Product warranty (yr) | 2 |
|---|---|
| Warranty provider | Kostal |
