PIKO 20 DCS INT (New Generation)
String inverter PIKO 20 with smart AC Switch
Art. no.
8230105
Manufacturer No.
10508900
Product details
Product information "PIKO 20 DCS INT (New Generation)"
***Only released with the following optimizers:
- Maxim Integrated
- Tigo Energy***
- Maxim Integrated
- Tigo Energy***
- 3-phase feed-in
- Transformerless converting
- Integrated electronic DC switch
- Broad input voltage range
- Standard integrated communication package with data logger, web server, solar portal and the following interfaces: 2x Ethernet, RS485, S0, 4x analogue inputs (e.g. for ripple control receivers or PIKO Sensor)
- PIKO BA Sensor can be connected for the measurement of building consumption and for dynamic active power control
- Integrated switch contact for self-consumption optimisation
- Smart Home-ready, EEBus 1.0-ready
Technical details
| Topology | transformerless |
|---|---|
| Max. generator power DC (kWp) | 30.00 |
| Max. input current DC (A) total | 60.00 |
| European efficiency (%) | 97.30 |
| Max. short circuit current per MPPT (A) | 25 |
| Interface 2 | RS485 |
| Display | with display |
| Arc Fault Circuit Interrupter | no |
| Number of independent MPPT (pcs) | 3 |
| Surge protection AC | type 3 |
| Max. input voltage DC (V) | 1000.00 |
| Degree of protection IP | IP55 |
| Max. AC power (kVA) | 20.00 |
| Interface 1 | Ethernet |
| Step-Up converter | yes |
| Max. input current per MPPT (A). | 20 |
| Min. temperature ambient (°C) | -20 |
| Max. efficiency (%) | 98.00 |
| MPP min. voltage range input (V) | 180.00 |
| AC nominal power (kW) | 20.00 |
| Start input voltage (V) | 180 |
| Decibel | 56 |
| Integrated DC switch | yes |
| MPP max. voltage range input (V) | 800.00 |
| Protection degree | IP55 |
| Total number of string inputs | 3 |
| Surge protection DC | type 2 |
| Integrated AC switch | yes |
| Max. short circuit current (A) total | 75.00 |
| DC connector type | SUNCLIX |
| Max. output current (A) | 32.20 |
| Intrastat country of origin | Germany |
|---|---|
| Intrastat product number (HS-code) | 85044086 |
| Manufacturer item name | PIKO 20 |
| Manufacturer | Kostal |
| Width incl. packaging (cm) | 80.00 |
|---|---|
| Amount per Pallet | 6 |
| Length incl. packaging (cm) | 60.00 |
| Height incl. packaging (cm) | 36.00 |
| Pack. material | cardboard box |
| Pal. dim. LxBxH (mm) | 1200x800x1200 |
| Weight incl. packaging (Kg) | 48.500 |
| Height without packaging (mm) | 265.00 |
|---|---|
| Width without packaging (mm) | 700.00 |
| Weight without packaging (kg) | 48.500 |
| Length without packaging (mm) | 540.00 |
| Product warranty (yr) | 2 |
|---|---|
| Warranty provider | Kostal |
