GW30K-MT (+DC-SWITCH/WIFI/SPD TYPE II/AFCI)
Three-phase string inverter with DC switch
Art. no.
8252719
Manufacturer No.
SMT0030-35-01P
Product details
Product information "GW30K-MT (+DC-SWITCH/WIFI/SPD TYPE II/AFCI)"
- 98.8% Max. Efficiency
- String level monitoring
- Fuse free
- String level monitoring
- Fuse free
Technical details
| Topology | transformerless |
|---|---|
| DC connector type | MC4 |
| AC nominal power (kW) | 30.00 |
| Max. AC power (kVA) | 33.00 |
| Step-Up converter | no |
| Protection degree | IP65 |
| Max. generator power DC (kWp) | 39.00 |
| Max. short circuit current (A) total | 112.50 |
| Total number of string inputs | 2 |
| Number of independent MPPT (pcs) | 3 |
| Max. output current (A) | 48.00 |
| Surge protection AC | type 2 |
| Interface 1 | RS485 |
| MPP max. voltage range input (V) | 950.00 |
| Display | w/o display |
| European efficiency (%) | 98.50 |
| Degree of protection IP | IP65 |
| Start input voltage (V) | 180 |
| Max. short circuit current per MPPT (A) | 37,5 |
| MPP min. voltage range input (V) | 200.00 |
| Integrated DC switch | yes |
| Max. input current per MPPT (A). | 30 |
| Max. efficiency (%) | 98.80 |
| Min. temperature ambient (°C) | -30 |
| Max. input voltage DC (V) | 1100.00 |
| Surge protection DC | type 2 |
| Arc Fault Circuit Interrupter | yes |
| Max. input current DC (A) total | 90.00 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer item name | GW30K-MT |
| Manufacturer | GoodWe |
| Intrastat product number (HS-code) | 85044086 |
| Weight incl. packaging (Kg) | 44.500 |
|---|---|
| Pal. weight (kg) | 287.50 |
| Length incl. packaging (cm) | 75.00 |
| Amount per Pallet | 6 |
| Amount p. Cont. | 276 |
| Pack. material | cardboard box |
| Width incl. packaging (cm) | 58.50 |
| Height incl. packaging (cm) | 31.00 |
| Pal. dim. LxBxH (mm) | 1240x800x1050 |
| Length without packaging (mm) | 590.00 |
|---|---|
| Height without packaging (mm) | 200.00 |
| Weight without packaging (kg) | 40.000 |
| Width without packaging (mm) | 480.00 |
| Warranty provider | GoodWe |
|---|---|
| Product warranty (yr) | 5 |
