Battery-Box Premium HVM 19.3
Set
HV storage, 19.32 kWh usable, BCU 2.0
Art. no.
8259923
Product details
Product information "Battery-Box Premium HVM 19.3"
CAUTION:
Hazardous material according to UN 3480 / Transport hazard class 9 / Packing Group II
Please check compatibility with your system. Retrofitting storage modules requires special preparations and must be carried out in accordance with the manufacturer's instructions.
Hazardous material according to UN 3480 / Transport hazard class 9 / Packing Group II
Please check compatibility with your system. Retrofitting storage modules requires special preparations and must be carried out in accordance with the manufacturer's instructions.
The wireless stacking concept for high-voltage storage systems was invented with the BYD Battery-Box. The compact and fast installation has now become the standard. The proven LFP cell chemistry, flexible scaling options and unlimited retrofitting make it a powerful success story. The HVM series enables up to 22.1 kWh per tower and up to 3 units in parallel. Ideal from home use to small commercial applications. Even faster installation thanks to the new BCU 2.0 and compatible with many leading manufacturers.
Product advantages:
- Proven wireless stacking design
- Up to 8 memory modules per unit
- Can be retrofitted indefinitely
Product features Memory:
- Battery capacity (usable): 19.32 kWh
- Nominal voltage: 358.4 V
- Expansion window: unlimited
- Structure per unit: 3 to 8 battery modules
- Number of units in parallel: 3
- Cell chemistry: LFP
- COM connections: RJ45
- BAT connections: MC4
- Protection class: IP55
- Dimensions: 1927 x 585 x 298 mm (HxWxD)
- Weight: 281.0 kg
Downloads
- Operations manual English
- Mounting Instructions English
- Warranty Terms English
- Datasheet English
- Declaration of Conformity English
-
B-BOX PREMIUM HVM (2,76 kWh)8231400
-
B-BOX PREMIUM HV BATTERY CONTROL UNIT + BASE8259471
Technical details
| Min. temperature ambient (°C) | -10 |
|---|---|
| Usable capacity (kWh) | 19.32 |
| Capacity extendable later | yes without restriction |
| Nominal voltage DC (V) | 358.40 |
| Cell chemistry | LFP |
| Battery voltage | High Voltage |
| Battery cell chemistry | LFP |
| Protection degree | IP55 |
| Intrastat country of origin | China |
|---|---|
| Hazardous goods Weight (net) (kg) | 281.000 |
| Hazardous goods transportation category | 2 |
| Hazardous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Intrastat product number (HS-code) | 85076000 |
| Manufacturer | BYD |
| Hazardous goods class | 9 |
| Hazardous goods packaging type | 4G |
| Manufacturer item name | HVM 19.3*BCU2.0*Base |
| UN No. | 3480 |
| Weight incl. packaging (Kg) | 290.400 |
|---|
| Weight without packaging (kg) | 279.300 |
|---|
| Warranty provider | BYD |
|---|
