Synergy Inverter SE-TRI, AC power 90 - 100 kW
String inverter, 3-ph, MC4, RSD, without DC switch
Art-No.
0164583
Manufacturer No.
SE-TRI-RW00IBNM4
Product details
Product information "Synergy Inverter SE-TRI, AC power 90 - 100 kW"
Suitable optimizers must be added separately.
SolarEdge's Synergy inverters now also offer selectable power classes in the commercial sector. This creates greater flexibility and reduces storage requirements. The modular system design with separate power units and Synergy Manager minimizes personnel requirements for assembly and installation. Integrated arc detection, surge protection, and the proven optimizer concept with thermal monitoring of DC connectors ensure safety and transparency in every application.
Product advantages:
• Flexibly selectable power classes
• Modular system design
• Integrated AFCI arc detection
Product features:
• AC rated power: 90.0 / 100.0 kW
• Feed phases: 3
• AC mains voltage: 400 V
• DC overvoltage protection: Type 2
• AC overvoltage protection: Type 2
• AFCI arc detection: yes
• Rapid shutdown: yes
• DC connector type: Stäubli MC4 (4 x per power unit)
• Interfaces: Ethernet, 2 x RS485, WiFi + LTE optional
• Protection class: IP65
• Cooling: active
• Weight: 32.0 kg (per power unit), 18.0 kg (Synergy Manager)
• Dimensions: 558 x 328 x 273 mm (per power unit), 360 x 560 x 295 mm (Synergy Manager)
• Warranty: 12 years (optional 20 years)
Downloads
-
SESUK-RWR0INNN80164044
-
Synergy Inverter SE-TRI, AC power 90 - 100 kW0163264
Technical details
| AC nominal power (kW) | 100.00 |
|---|---|
| Surge protection AC | type 2 |
| Arc Fault Circuit Interrupter | yes |
| DC connection | MC4 |
| Surge protection DC | type 2 |
| Decibel | 67 |
| Display | w/o display |
| Feed-in phases | 3 |
| European efficiency (%) | 98.00 |
| Protection degree | IP65 |
| Total number of string inputs | 12 |
| Integrated DC switch | no |
| Max. AC power (kVA) | 100.00 |
| Max. output current (A) | 145.00 |
| Max. generator power DC (kWp) | 175.00 |
| Max. input voltage DC (V) | 1000.00 |
| Max. input current DC (A) total | 144.75 |
| Max. efficiency (%) | 98.30 |
| Min. temperature ambient (°C) | -40 |
| Offgrid usable | no |
| Rapid shutdown | yes |
| Interface 1 | Ethernet |
| Interface 2 | RS485 |
| Topology | transformerless |
| Manufacturer | SolarEdge |
|---|---|
| Manufacturer item name | SE-TRI-RW00IBNM4*SESUK-RWR0INNN8 |
| Intrastat country of origin | United States of Amerika |
| Intrastat product number (HS-code) | 85044087 |
| Weight incl. packaging (Kg) | 123.740 |
|---|
| Weight without packaging (kg) | 114.000 |
|---|
| Warranty provider | SolarEdge |
|---|---|
| Standard product warranty (yr) | 12 |
