SigenStor 10.0 + Sigen Hybrid Inverter 8.0 TP2
HV-storage system, 8.76 kWh, 8.0 kW IV, 3-phase
Art-No.
0165165
Product details
Product information "SigenStor 10.0 + Sigen Hybrid Inverter 8.0 TP2"
Sigenergy’s TP2 series three-phase hybrid inverter is part of a modular storage concept designed for residential applications. This ultra-slim inverter is available in power classes ranging from 3 to 12 kW and can be flexibly combined with SigenStor BAT storage modules. These modules come in two sizes, offering 5.84 kWh and 8.76 kWh of usable capacity. At maximum configuration—using six batteries—a total capacity of up to 52.56 kWh can be achieved. The integrated backup connection ensures power supply to even sensitive loads with a switchover time of less than 0 ms. Product advantages:
• Flexible combinations with SigenStor BAT storage
• Up to 32 A input current per MPPT
System product features:
• Rated AC power: 8.0 kW
• Grid feed-in phases: 3
• AC grid voltage: 400 V
• Storage connection: High-voltage
• Number of MPPTs: 2
• Max. DC input voltage: 1100 V
• DC surge protection: Type 2
• AC surge protection: Type 2
• AFCI arc detection: Yes
• DC connector type: Amphenol H4
• Backup: Yes (integrated connection)
• Communication: Wi-Fi, LAN, RS485, Sigen CommMod (3G/4G – optional), 5 x DI (grid control/ripple control + §14a)
• Protection class: IP66
• Cooling: Passive
• Dimensions: 477 x 568 x 99 mm
• Weight: 19.5 kg
Storage product features:
• Usable battery capacity: 8.76 kWh
• Storage type: High-voltage
• Expansion timeframe: Unlimited
• Number of storage modules per unit: 1 to 6
• Cell chemistry: LFP
• Cooling: Passive
• Protection class: IP66
• Dimensions: 767 x 270 x 265 mm
• Weight: 78.0 kg each
Scope of delivery:
• 1 × Sigen Hybrid 8.0 TP2, hybrid inverter (Item 0162462)
• 1 × SigenStor Battery 10.0, storage module (Item 0161481)
• 1 × SigenStor Battery Controller (Item 0162213)
• 1 × SigenStor installation kit for ground mounting (Item 0161483)
• 1 × Sigen Sensor TP-DH (Item 0161494)
Caution
| Dangerous goods Weight (net) (kg) | 78.000 |
|---|---|
| Dangerous goods transportation category | 2 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
Downloads
-
SigenStor Installation Kit for ground-mounting0161483
-
SigenStor Battery Controller0162213
-
Sigen Hybrid Inverter 8.0 TP20162462
-
Sensor TP-DH0161494
-
SigenStor Battery 10.00161481
-
Sigen Hybrid Inverter 8.0 TP20162462
-
Sensor TP-DH0161494
-
SigenStor Battery 10.00161481
Technical details
| Topology | transformerless |
|---|---|
| Max. nominal charging power (kW) | 4.60 |
| Max. AC power (kVA) | 8.80 |
| Max. input current per MPPT (A). | 16 |
| Backup system full | yes with supply |
| Protection degree | IP66 |
| Number of independent MPPT (pcs) | 2 |
| Total number of string inputs | 2 |
| Max. input current DC (A) total | 32.00 |
| Surge protection AC | type 2 |
| Max. output current (A) | 13.40 |
| Rapid shutdown | yes |
| Display | w/o display |
| European efficiency (%) | 98.50 |
| Min. temperature ambient (°C) | -20 |
| Max. generator power DC (kWp) | 16.00 |
| Start input voltage (V) | 180 |
| Battery cell chemistry | LFP |
| Max. discharging power (kW) | 4.60 |
| MPP min. voltage range input (V) | 160.00 |
| Integrated DC switch | yes |
| Max. short circuit current per MPPT (A) | 22 |
| Decibel | 28 |
| Usable capacity (kWh) | 8.76 |
| Max. input voltage DC (V) | 1100.00 |
| Surge protection DC | type 2 |
| AC nominal power (kW) | 8.00 |
| Grid protection | yes |
| Arc Fault Circuit Interrupter | yes |
| Max. efficiency (%) | 99.00 |
| MPP max. voltage range input (V) | 1000.00 |
| Max. short circuit current (A) total | 44.00 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer item name | SIGENSTOR BAT 10.0 + SIGEN HYBRID 8.0 TP2 |
| Dangerous goods Weight (net) (kg) | 78.000 |
| Dangerous goods transportation category | 2 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Intrastat product number (HS-code) | 85076000 |
| Manufacturer | Sigenergy |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
| Weight incl. packaging (Kg) | 140.100 |
|---|
| Weight without packaging (kg) | 116.020 |
|---|
