S800S for roof systems
Micro inverter, 1-ph, 2 MPPT, MC4
Art-No.
0156984
Manufacturer No.
ASP00041
Skip product gallery
Matching accessories
Sungrow
0157783
T-adapter cable for 450S / S800S / S1000S / S1600S
AC connection cable with outlet for 1 Mic-WR,2.8 m
Product details
Product information "S800S for roof systems"
Additional accessories are essential for installation. Please check in advance which accessories are required.
Following the motto "Small but mighty," Sungrow offers microinverters in three power classes for rooftop applications. Equipped with 0.45 to 1.6 kW and up to 4 MPP trackers and Wi-Fi, they offer maximum flexibility for all applications. Thanks to plug-and-play connectors, additional components – which can be selected individually depending on the configuration – can be installed quickly and securely.
Product advantages:
• Flexible for a wide range of applications
Product features:
• AC power: 0.8 kW
• Feed-in phases: 1
• AC mains voltage: 230 V
• Number of MPP trackers: 2
• Max. DC input voltage: 16 – 60 V
• Max. DC input current: 16 A per MPPT
• DC connector type: Stäubli MC4
• AC surge protection: Type 2
• Interfaces: Wi-Fi
• Housing protection class: IP67
• Cooling: passive
• Dimensions: 226 x 265 x 42 mm (H x W x D)
• Weight: 3.5 kg
Technical details
| AC nominal power (kW) | 0.80 |
|---|---|
| Number of independent MPPT (pcs) | 2 |
| Arc Fault Circuit Interrupter | no |
| DC connection | MC4 |
| Display | with display |
| Feed-in phases | 1 |
| European efficiency (%) | 95.40 |
| Protection degree | IP67 |
| Total number of string inputs | 2 |
| Max. AC power (kVA) | 0.80 |
| Max. output current (A) | 3.60 |
| Max. generator power DC (kWp) | 8.00 |
| Max. input voltage DC (V) | 60.00 |
| Max. input current DC (A) total | 32.00 |
| Max. input current per MPPT (A). | 16 |
| Max. short circuit current (A) total | 40.00 |
| MPP max. voltage range input (V) | 60.00 |
| Max. efficiency (%) | 96.20 |
| Min. voltage range input (V) | 16 |
| MPP min. voltage range input (V) | 16.00 |
| Min. temperature ambient (°C) | -40 |
| Interface 1 | W-Lan |
| Start input voltage (V) | 22 |
| Topology | transformerless |
| Manufacturer | Sungrow |
|---|---|
| Manufacturer item name | S800S |
| Intrastat country of origin | China |
| Intrastat product number (HS-code) | 85044084 |
| Length incl. packaging (cm) | 6.00 |
|---|---|
| Width incl. packaging (cm) | 47.50 |
| Height incl. packaging (cm) | 27.40 |
| Weight incl. packaging (Kg) | 4.300 |
| Amount per Pallet | 96 |
| Amount per big Box | 8 |
| Pal. weight (kg) | 450.60 |
| Pal. dim. LxBxH (mm) | 1200x1010x1149 |
| Pack. material | cardboard box |
| Length without packaging (mm) | 42.00 |
|---|---|
| Width without packaging (mm) | 265.00 |
| Height without packaging (mm) | 226.00 |
| Weight without packaging (kg) | 3.500 |
| Warranty provider | Sungrow |
|---|---|
| Standard product warranty (yr) | 25 |
