S450S for balcony systems
Micro inverter, 1-ph, 1 MPPT, MC4
Art-No.
0159727
Manufacturer No.
ASP00047
Product details
Product information "S450S for balcony systems"
Following the motto "Small but beautiful," Sungrow offers micro inverters for trendy balcony systems. Equipped with 0.45/0.8 kW, up to 2 MPP trackers, and Wi-Fi, they offer maximum flexibility for even the smallest of home systems. Plug-and-play connectors on the AC and DC sides ensure quick and safe installation.
Product advantages:
• Smart integration into the home network
• Integrated grid and network protection
Product features:
• AC power: 0.45 kW
• Feed-in phases: 1
• AC mains voltage: 230 V
• Number of MPP trackers: 1
• Max. DC input voltage: 16 – 60 V
• Max. DC input current: 16 A per MPPT
• DC connector type: Stäubli MC4
• AC surge protection: Type 2
• Interfaces: Wi-Fi
• Housing protection class: IP67
• Cooling: passive
• Dimensions: 168 x 238 x 42 mm (H x W x D)
• Weight: 2.5 kg
Technical details
| AC nominal power (kW) | 0.45 |
|---|---|
| Number of independent MPPT (pcs) | 1 |
| Arc Fault Circuit Interrupter | no |
| DC connection | MC4 |
| Feed-in phases | 1 |
| European efficiency (%) | 95.40 |
| Protection degree | IP67 |
| Total number of string inputs | 1 |
| Max. AC power (kVA) | 0.45 |
| Max. output current (A) | 2.10 |
| Max. generator power DC (kWp) | 0.57 |
| Max. input voltage DC (V) | 60.00 |
| Max. input current DC (A) total | 16.00 |
| Max. input current per MPPT (A). | 16 |
| Max. short circuit current (A) total | 20.00 |
| MPP max. voltage range input (V) | 60.00 |
| Max. efficiency (%) | 96.20 |
| Min. voltage range input (V) | 16 |
| MPP min. voltage range input (V) | 16.00 |
| Min. temperature ambient (°C) | -40 |
| Interface 1 | W-Lan |
| Start input voltage (V) | 22 |
| Manufacturer | Sungrow |
|---|---|
| Manufacturer item name | S450S |
| Intrastat country of origin | China |
| Intrastat product number (HS-code) | 85044084 |
| Length incl. packaging (cm) | 6.00 |
|---|---|
| Width incl. packaging (cm) | 47.50 |
| Height incl. packaging (cm) | 21.00 |
| Weight incl. packaging (Kg) | 3.200 |
| Amount per Pallet | 128 |
| Amount per big Box | 8 |
| Pal. weight (kg) | 411.00 |
| Pal. dim. LxBxH (mm) | 1200x1000x1234 |
| Pack. material | cardboard box |
| Length without packaging (mm) | 42.00 |
|---|---|
| Width without packaging (mm) | 238.00 |
| Height without packaging (mm) | 168.00 |
| Weight without packaging (kg) | 2.500 |
| Warranty provider | Sungrow |
|---|---|
| Standard product warranty (yr) | 15 |
