GW50K-ET-10
Product information "GW50K-ET-10"
· Supports parallel connection in both on- and off-grid modes
· Up to 150% DC input oversizing
· 4 MPPTs, Max. efficiency up to 98.1%
Optional Type I+II SPD on DC side
· IP66 protection for outdoor installation safety
· AFCI optional
GoodWe's ET Series inverters, available in 40kW and 50kW capacities, are designed for commercial and industrial PV installations. These adaptable inverters seamlessly integrate into both on-grid and off-grid applications, facilitating parallel connections in either scenario. When paired with the Static Transfer Switch (STS) Box from GoodWe, the inverter not only ensures dependable UPS-level switching to backup mode but also interacts with diesel generators to efficiently replenish batteries. Moreover, the ET Series is compatible with diverse battery capacities and brands, including the GoodWe Lynx C, offering a comprehensive energy storage solution.
Technical details
| Max. AC power (kVA) | 50.00 |
|---|---|
| Topology | transformerless |
| Min. voltage range input (V) | 165 |
| Total number of string inputs | 8 |
| Max. input current DC (A) total | 148.00 |
| Interface 2 | W-Lan |
| Charging voltage (V) | 200 - 800 |
| Protection degree | IP66 |
| Start input voltage (V) | 200 |
| MPP max. voltage range input (V) | 850.00 |
| Number of independent MPPT (pcs) | 4 |
| Contact for self-consumption optimization (e.g. for heat pump) | 1 |
| Backup system full | no |
| Min. temperature ambient (°C) | -35 |
| Max. input voltage DC (V) | 1000.00 |
| Surge protection AC | type 2 |
| MPP min. voltage range input (V) | 165.00 |
| Max. input current per MPPT (A). | 42/32/42/32 |
| Degree of protection IP | IP66 |
| Interface 1 | RS485 |
| Feed-in phases | 3 |
| European efficiency (%) | 97.50 |
| Battery Connection | AC/DC |
| Peak shaving | yes |
| Max. short circuit current (A) total | 194.00 |
| Display | w/o display |
| Charging current (A) | 100.00 |
| Max. short circuit current per MPPT (A) | 55/42/55/42 |
| Max. efficiency (%) | 98.10 |
| Integrated DC switch | yes |
| Offgrid usable | yes |
| Backup system light | yes with supply |
| Decibel | 65 |
| Integrated AC switch | no |
| Arc Fault Circuit Interrupter | yes |
| Max. output current (A) | 72.50 |
| AC nominal power (kW) | 50.00 |
| Max. generator power DC (kWp) | 75.00 |
| Surge protection DC | type 1 and type 2 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer | GoodWe |
| Intrastat product number (HS-code) | 85044084 |
| Manufacturer item name | GW50K-ET-10 |
| Weight incl. packaging (Kg) | 74.400 |
|---|---|
| Height incl. packaging (cm) | 50.00 |
| Width incl. packaging (cm) | 92.00 |
| Length incl. packaging (cm) | 135.00 |
| Width without packaging (mm) | 520.00 |
|---|---|
| Length without packaging (mm) | 260.00 |
| Height without packaging (mm) | 660.00 |
| Weight without packaging (kg) | 65.000 |
| Warranty provider | GoodWe |
|---|---|
| Product warranty (yr) | 5 |
