STP 110-60 CORE2 WITH AFCI
Sunny Tripower 110-60 Core2
Art. no.
8252387
Manufacturer No.
202724-00.01
Product details
Product information "STP 110-60 CORE2 WITH AFCI"
PV inverter for mains supply Pac,r/Sac,max 110000 W/ 110000 VA,
threephase feed-in, with reactive power supply, transformerless, Ethernet
communication interface, browser-based setup of the
country settings, 12 independent MPP trackers, 24 DC inputs,
fuseless DC design, Sunclix connection, integrated DC switch-disconnector,
AC connector for copper or aluminum conductors, DC surge arrester
Type I/II, Type II AC surge arrester, with
integrated AFC
Technical details
| Topology | transformerless |
|---|---|
| Start input voltage (V) | 250 |
| Max. output current (A) | 159.00 |
| Max. AC power (kVA) | 110.00 |
| MPP min. voltage range input (V) | 500.00 |
| Min. voltage range input (V) | 200 |
| Protection degree | IP66 |
| Max. generator power DC (kWp) | 165.00 |
| Max. input current DC (A) total | 312.00 |
| Total number of string inputs | 24 |
| Surge protection AC | type 2 |
| Degree of protection IP | IP66 |
| Interface 1 | Ethernet |
| Max. efficiency (%) | 98.60 |
| Rapid shutdown | no |
| Number of independent MPPT (pcs) | 12 |
| Max. short circuit current per MPPT (A) | 40 |
| Max. input current per MPPT (A). | 26 |
| Step-Up converter | yes |
| Display | w/o display |
| AC nominal power (kW) | 110.00 |
| Integrated DC switch | yes |
| Min. temperature ambient (°C) | -30 |
| MPP max. voltage range input (V) | 800.00 |
| European efficiency (%) | 98.40 |
| Max. input voltage DC (V) | 1100.00 |
| UI curve diagnosis | no |
| Decibel | 78 |
| Integrated AC switch | no |
| Arc Fault Circuit Interrupter | yes |
| Max. short circuit current (A) total | 480.00 |
| Shadow management | yes |
| DC connector type | SUNCLIX |
| Surge protection DC | type 1 and type 2 |
| String fuses | not included |
| Intrastat country of origin | China |
|---|---|
| Manufacturer | SMA |
| Intrastat product number (HS-code) | 85044086 |
| Manufacturer item name | Sunny Tripower CORE2 |
| Pal. weight (kg) | 125.00 |
|---|---|
| Amount per Pallet | 1 |
| Width incl. packaging (cm) | 84.00 |
| Pal. dim. LxBxH (mm) | 1220x840x610 |
| Pack. material | cardboard box |
| Length incl. packaging (cm) | 122.00 |
| Height incl. packaging (cm) | 61.00 |
| Weight incl. packaging (Kg) | 125.000 |
| Width without packaging (mm) | 363.00 |
|---|---|
| Height without packaging (mm) | 682.00 |
| Weight without packaging (kg) | 93.500 |
| Length without packaging (mm) | 1117.00 |
| Warranty provider | SMA |
|---|---|
| Product warranty (yr) | 5 |
