GW25K-ET
Product information "GW25K-ET"
With the new performance classes of its ET-Hybrid series from 15 to 29.9 kW, With a clear focus on the new system sizes, the devices also come with the right key data. Up to 17 amps per DC connection, 38 amps per MPP tracker and up to 2 battery inputs with 50 amps charging current each. In addition, a powerful backup UPS function < 10ms. Goodwe even lists peak shaving as a betting option.
Product advantages:
• Hybrids in new, attractive performance classes
• Emergency power with UPS function < 10ms
• 38A input current per MPPT
• Energy meter included with inverter
• Type 2 DC overvoltage protection integrated
Product features:
• AC power: 25 kW
• Number of MPPT: 3
• AC connection: 3-phase
• Memory connections: 2
• Communication: Wifi, RS485
• Protection class: IP66
• Cooling: active
• Weight: 54.0 kg
Technical details
| Topology | transformerless |
|---|---|
| AC nominal power (kW) | 25.00 |
| Total number of string inputs | 6 |
| Interface 2 | W-Lan |
| Step-Up converter | no |
| Protection degree | IP66 |
| Max. input current per MPPT (A). | 30,0 |
| Start input voltage (V) | 200 |
| Max. generator power DC (kWp) | 37.50 |
| MPP max. voltage range input (V) | 850.00 |
| Arc Fault Circuit Interrupter | no |
| Number of independent MPPT (pcs) | 3 |
| Surge protection AC | type 3 |
| Max. output current (A) | 39.90 |
| Min. temperature ambient (°C) | -35 |
| Max. short circuit current per MPPT (A) | 38,0 |
| Max. input voltage DC (V) | 1000.00 |
| Degree of protection IP | IP66 |
| Interface 1 | RS485 |
| Battery connection | DC |
| European efficiency (%) | 97.50 |
| Display | w/o display |
| Charging current (A) | 100.00 |
| Max. efficiency (%) | 98.00 |
| Max. short circuit current (A) total | 114.00 |
| Charging voltage (V) | 500 |
| MPP min. voltage range input (V) | 200.00 |
| Integrated DC switch | yes |
| Offgrid usable | yes |
| Max. AC power (kVA) | 27.50 |
| Surge protection DC | type 2 |
| Max. input current DC (A) total | 90.00 |
| Min. voltage range input (V) | 620 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer | GoodWe |
| Intrastat product number (HS-code) | 85044086 |
| Manufacturer item name | GW25K-ET |
| Amount per Pallet | 4 |
|---|---|
| Length incl. packaging (cm) | 87.00 |
| Amount p. Cont. | 168 |
| Weight incl. packaging (Kg) | 63.000 |
| Height incl. packaging (cm) | 33.00 |
| Pack. material | cardboard box |
| Width incl. packaging (cm) | 65.00 |
| Pal. weight (kg) | 267.00 |
| Pal. dim. LxBxH (mm) | 1350x920x800 |
| Width without packaging (mm) | 520.00 |
|---|---|
| Length without packaging (mm) | 660.00 |
| Height without packaging (mm) | 220.00 |
| Weight without packaging (kg) | 54.000 |
| Warranty provider | GoodWe |
|---|---|
| Product warranty (yr) | 5 |
