T-BAT SYS HS50E
HV storage module, 4.6 kWh usable, IES system
Art-No.
0159749
Manufacturer No.
102012020310
Product details
Product information "T-BAT SYS HS50E"
This storage module is part of the Solax IES All-in-One modular system. The BMS and inverter must be added separately.
For more than three storage modules, the system must be configured with the Series Box in two towers.
The IES series from Solax is a compact, all-in-one home energy storage system. Inverters, BMS, and batteries form a seamless unit. The inverters are available in single-phase and three-phase versions with power ratings from 2.5 to 15 kW. Depending on the model, up to six storage modules are possible. With a usable capacity of 4.6 kWh per module, a total of up to 27.6 kWh can be installed. There is no time limit for expansion. For configurations with more than three storage modules, the Solax Series Box HS50E is used to create a two-tower system.
Product advantages:
• Flexible configuration thanks to modular system
• Proven wireless stacking design
• Updates and diagnostics via the inverter
Product specifications:
• Battery capacity (usable): 4.6 kWh
• Storage type: High voltage
• Expansion timeframe: Unlimited
• Number of storage modules in one unit: 1 to 6
(From the 3rd storage unit onwards, the Series Box can be used to build two towers)
• Cell chemistry: LFP
• Communication: RS485
• Cooling: Passive
• Protection class: IP66
• Dimensions: 318 x 730 x 150 mm (H x W x D)
• Weight: 47.0 kg
Wichtige technische Daten
| Dangerous goods transportation category | 2 |
|---|---|
| Dangerous goods Weight (net) (kg) | 46.000 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
Technical details
| Protection degree | IP66 |
|---|---|
| Max. output current discharging (A) | 50.00 |
| Capacity extendable later | yes without restriction |
| Usable capacity (kWh) | 4.60 |
| Cell chemistry | LFP |
| Battery voltage | High Voltage |
| Battery cell chemistry | LFP |
| Nominal voltage DC (V) | 102.40 |
| Nominal Capacity (Ah) | 49.80 |
| Max. output current charging (A) | 50.00 |
| Intrastat country of origin | China |
|---|---|
| Dangerous goods transportation category | 2 |
| Manufacturer | SolaX Power |
| Dangerous goods Weight (net) (kg) | 46.000 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Intrastat product number (HS-code) | 85076000 |
| Dangerous goods class | 9 |
| Manufacturer item name | HS50E |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
| Pack. material | cardboard box |
|---|---|
| Weight incl. packaging (Kg) | 51.450 |
| Amount per big Box | 1 |
| Height incl. packaging (cm) | 43.00 |
| Amount per Pallet | 20 |
| Width incl. packaging (cm) | 25.40 |
| Length incl. packaging (cm) | 79.00 |
| Height without packaging (mm) | 318.00 |
|---|---|
| Weight without packaging (kg) | 47.000 |
| Length without packaging (mm) | 730.00 |
| Width without packaging (mm) | 150.00 |
| Standard product warranty (yr) | 10 |
|---|---|
| Warranty provider | SolaX Power |
| Product warranty (yr) | 10 |
