SUN5000-150K-MG0, string inverter
Product information "SUN5000-150K-MG0, string inverter"
The SUN5000 model series from Huawei can only be operated fully optimised. Compatible optimisers are listed below as accessories.
The 150K-MG0 closes another gap in Huawei's broad portfolio. With connection to the 400 volt low-voltage grid in accordance with the current VDE-AR-N 4105 standard, integrated AC + DC overvoltage protection and AFCI arc detection. The full optimisation of the SUN5000 series also enables monitoring and safety management at module level. Cost-efficient double optimisers with up to 1300 Wp enable a wide range of high-performance modules to be used.
Product advantages:
- Optimisation and monitoring at module level
- Cost-efficient design with MERC double optimisers 1100W-P and 1300W-P
- Integrated AFCI arc detection
- AC + DC overvoltage protection type 2
Product features:
- AC power: 150.0 kW
- AC connection: 400V, 3-phase
- DC input voltage: 1100 V
- DC input current: 66 A total
- DC connections: 12
- DC connector: Amphenol HH4
- Communication: RS485 (Wifi / 4G optional)
- Protection class: IP66
- Cooling: active
- Dimensions: 710 x 1000 x 395 mm (H x W x D)
- Weight: 102.0 kg
Compatible optimisers:
- Huawei MERC-1100W-P
- Huawei MERC-1300W-P
Technical details
| Topology | transformerless |
|---|---|
| Max. short circuit current (A) total | 66.00 |
| Min. voltage range input (V) | 200 |
| Min. temperature ambient (°C) | -25 |
| Protection degree | IP66 |
| Max. generator power DC (kWp) | 165.00 |
| Surge protection AC | type 2 |
| Total number of string inputs | 12 |
| Degree of protection IP | IP66 |
| Interface 1 | RS485 |
| Max. efficiency (%) | 98.60 |
| Display | w/o display |
| Max. output current (A) | 253.20 |
| AC nominal power (kW) | 150.00 |
| MPP min. voltage range input (V) | 200.00 |
| Max. input current DC (A) total | 336.00 |
| European efficiency (%) | 98.40 |
| Max. input voltage DC (V) | 1100.00 |
| Surge protection DC | type 2 |
| DC connector type | H4Amphenol |
| Arc Fault Circuit Interrupter | yes |
| Number of independent MPPT (pcs) | 7 |
| MPP max. voltage range input (V) | 1000.00 |
| Max. AC power (kVA) | 165.00 |
| Intrastat country of origin | China |
|---|---|
| Intrastat product number (HS-code) | 85044086 |
| Manufacturer item name | SUN5000-150K-MG0 |
| Manufacturer | Huawei |
| Weight incl. packaging (Kg) | 100.000 |
|---|---|
| Amount per Pallet | 2 |
| Pack. material | cardboard box |
| Height without packaging (mm) | 395.00 |
|---|---|
| Weight without packaging (kg) | 100.000 |
| Width without packaging (mm) | 710.00 |
| Length without packaging (mm) | 100.00 |
