3-PHASE METER DTSU666-20
for indirect measurement, 3-phase
Art-No.
0154200
Manufacturer No.
UT000138
Product details
Product information "3-PHASE METER DTSU666-20"
The required measuring transformers with 100 / 250 A must be ordered separately
Can be used with devices from the V20 and V11.2 series
When using 6 CTs, the same sizes must be used
The indirectly measuring Energy Meter DTSU666-20 from Sungrow is the ideal measurement device for systems with a larger grid connection and other energy generators. The total of 6 measuring transformers enable flexible energy recording. The small dimensions of the measuring transformers with 100 / 250 A enable quick and easy installation. It is already included in the scope of delivery of the hybrid devices in the T series.
Product features:
• AC connection: 3-phase, 400 V / 50Hz
• Communication: RS485
• Measurement type: indirect
• Measuring transformer connections: 6* (grid connection + ext. WR)
*The measuring transformers must be ordered separately
Technical details
| Feed-in phases | 3 |
|---|---|
| Type of AC measurement | indirect |
| Mounting type | DIN rail |
| Max. input current (A) total | 250.00 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer item name | UT000138 |
| Manufacturer | Sungrow |
| Intrastat product number (HS-code) | 85176990 |
| Amount per Pallet | 768 |
|---|---|
| Length incl. packaging (cm) | 35.00 |
| Pack. material | cardboard box |
| Weight incl. packaging (Kg) | 0.310 |
| Height incl. packaging (cm) | 24.00 |
| Width incl. packaging (cm) | 27.00 |
| Length without packaging (mm) | 72.00 |
|---|---|
| Weight without packaging (kg) | 0.260 |
| Width without packaging (mm) | 66.00 |
| Height without packaging (mm) | 118.00 |
| Standard product warranty (yr) | 2 |
|---|---|
| Warranty provider | Sungrow |
