Battery Module FH10050
-
Art. no.
6654119
Manufacturer No.
FH10050
Product details
Product information "Battery Module FH10050"
Observe the manufacturer's specifications regarding expansion and compatibility.
Compact, reliable and powerful – these are the new Force H3 high-voltage storage systems from Pylontech. With their proven and efficient stackable design, modelled on the H1 + H2 series, these powerhouses always find a place. With their expandable battery modules offering up to 34.01 kWh of usable capacity, they are ideal for home and small commercial applications.
Product features Storage:
• Usable battery capacity: 4.85 kWh
• Storage type: High-voltage
• Nominal voltage: 51.2 V
• Time window extension: up to 2 years (to be clarified)
• Number of storage modules in one unit: 2 to 7
• Cell chemistry: LFP
• Cooling: passive
• Protection class: IP55
• Dimensions: 170 x 540 x 350 mm (H x W x D)
• Weight: 39.0 kg
Technical details
| Nominal Capacity (Ah) | 50.00 |
|---|---|
| Max. output current discharging (A) | 50.00 |
| Min. temperature ambient (°C) | -10 |
| Capacity extendable later | yes with time restriction |
| Battery voltage | High Voltage |
| Battery cell chemistry | LFP |
| Usable capacity (kWh) | 5.12 |
| Nominal voltage DC (V) | 102.40 |
| Protection degree | IP55 |
| Max. output current charging (A) | 50.00 |
| Intrastat country of origin | China |
|---|---|
| Dangerous goods transportation category | 2 |
| Dangerous goods Weight (net) (kg) | 39.000 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Intrastat product number (HS-code) | 85076000 |
| Manufacturer item name | FH10050 |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| Manufacturer | Pylontech |
| UN No. | 3480 |
| Length incl. packaging (cm) | 59.00 |
|---|---|
| Amount p. Cont. | 220 |
| Pal. dim. LxBxH (mm) | 1150x1000 |
| Pack. material | cardboard box |
| Weight incl. packaging (Kg) | 45.000 |
| Pal. weight (kg) | 550.00 |
| Height incl. packaging (cm) | 24.00 |
| Amount Pal. p. Cont. | 22 |
| Width incl. packaging (cm) | 38.00 |
| Amount per Pallet | 10 |
| Weight without packaging (kg) | 39.000 |
|---|---|
| Width without packaging (mm) | 350.00 |
| Length without packaging (mm) | 540.00 |
| Height without packaging (mm) | 170.00 |
| Standard product warranty (yr) | 10 |
|---|---|
| Warranty provider | Pylontech |
| Product warranty (yr) | 10 |
