B-Box Premium HVM Battery Module
HV storage module, 2.76 kWh usable
Art. no.
6642227
Manufacturer No.
14039384-00
Product details
Product information "B-Box Premium HVM Battery Module"
Please check compatibility with your system. Retrofitting storage modules requires special preparations and must be carried out in accordance with the manufacturer's instructions.
The wireless stacking concept for high-voltage storage systems was invented with the BYD Battery-Box. The compact and fast installation has now become the standard. The proven LFP cell chemistry, flexible scaling options and unlimited retrofitting make it a powerful success story. The HVM series enables up to 22.1 kWh per tower and up to 3 units in parallel. Ideal from home use to small commercial applications. Compatible with many leading manufacturers.
Product benefits:
- Proven wireless stacking design
- Up to 8 storage modules per unit
- Can be retrofitted indefinitely
Product features Memory:
- Battery capacity (usable): 2.76 kWh
- Expansion time frame: unlimited
- Structure per unit: 3 to 8 battery modules
- Cell chemistry: LFP
- Nominal voltage: 51.2 V
- Protection class: IP55
- Dimensions: 233 x 585 x 298 mm (HxWxD)
- Weight: 38.0 kg
Technical details
| Protection degree | IP55 |
|---|---|
| Max. output current discharging (A) | 50.00 |
| Max. output current charging (A) | 50.00 |
| Min. temperature ambient (°C) | -10 |
| Nominal Capacity (Ah) | 54.50 |
| Nominal voltage DC (V) | 51.20 |
| Usable capacity (kWh) | 2.76 |
| Battery cell chemistry | LFP |
| Dangerous goods description | LITHIUM ION BATTERIES |
|---|---|
| Dangerous goods Weight (net) (kg) | 38.000 |
| Dangerous goods class | 9 |
| Dangerous goods transportation category | 2 |
| UN No. | 3480 |
| Dangerous goods packaging type | 4G |
| Manufacturer | BYD |
| Manufacturer item name | HVM 2.76 |
| Intrastat country of origin | China |
| Intrastat product number (HS-code) | 85076000 |
| Classification code | M4 |
| Tunnel restriction code | (E) |
| Length incl. packaging (cm) | 65.80 |
|---|---|
| Width incl. packaging (cm) | 36.80 |
| Height incl. packaging (cm) | 29.60 |
| Weight incl. packaging (Kg) | 41.700 |
| Amount per Pallet | 15 |
| Amount Pal. p. Cont. | 38 |
| Amount p. Cont. | 570 |
| Pal. weight (kg) | 640.00 |
| Pal. dim. LxBxH (mm) | 1200x760x1750 |
| Pack. material | cardboard box |
| Length without packaging (mm) | 585.00 |
|---|---|
| Width without packaging (mm) | 298.00 |
| Height without packaging (mm) | 296.00 |
| Weight without packaging (kg) | 38.000 |
| Warranty provider | BYD |
|---|
