UMG 604-PRO Network Analyzer
Product information "UMG 604-PRO Network Analyzer"
Suitable measuring transducers must be added separately in the appropriate quantity.
Please check compatibility based on the approvals of the other components used (manufacturer EMS, EZA controller, etc.).
The UMG 604-PRO is the Swiss army knife of multifunction measuring devices. The network analyzer can also be used for energy data acquisition for energy management in large commercial systems. The network interface with numerous IP protocols allows connection to EMS systems from a wide range of manufacturers.
Product advantages:
• Connection to a wide range of manufacturers possible
• Certified measurement accuracy for commercial applications
Product features:
• Power supply: 230 V
• Voltage measurement inputs: 3-/4-wire systems
• Current measurement inputs: 4
• Nominal current measurement: 5 A
• Measurement: indirect
• Interfaces: 1 x AI, 1 x DI, 2 x DO
• Communication: Ethernet, RS485, RS232, Modbus RTU, Modbus TCP
• Mounting: DIN rail
• Dimensions: 6 TE, 107 x 90 x 82 (L x W x H)
• Weight: 0.35 kg
Technical details
| Max. input current (A) total | 5.00 |
|---|---|
| Type of AC measurement | indirect |
| Mounting type | DIN rail |
| Intrastat product number (HS-code) | 90303200 |
|---|---|
| Intrastat country of origin | Germany |
| Manufacturer item name | UMG 604-PRO |
| Manufacturer | Janitza |
| Weight incl. packaging (Kg) | 0.600 |
|---|---|
| Height incl. packaging (cm) | 14.00 |
| Pack. material | cardboard box |
| Length incl. packaging (cm) | 18.00 |
| Width incl. packaging (cm) | 16.50 |
| Weight without packaging (kg) | 0.350 |
|---|---|
| Length without packaging (mm) | 107.50 |
| Width without packaging (mm) | 90.00 |
| Height without packaging (mm) | 82.00 |
| Warranty provider | Janitza |
|---|
