Power Stack Commercial Storage
Product information "Power Stack Commercial Storage"
CAUTION:
UN 3480 Lithium ion batteries / Transport hazard class 9 / (E)
Packing Group II
The manufacturer's specifications for installation, assembly, and location must be observed.
One EMS300CP controller is required per system (or grid connection point) with up to 25 Sungrow Power Stacks, as well as a suitable smart meter. Since this article does not include a controller or meter, they may need to be ordered separately.
In addition to the EMS300CP, an external EMS (3rd party) is required per system to provide the required control interfaces.
Due to the high total weight due to complete pre-assembly, suitable vehicles must be used for unloading and transport.
Off-grid or emergency power system applications cannot be implemented with the Sungrow Power Stack.
With the Power Stack Commercial Storage System, Sungrow is now also entering the large-scale storage segment. The key specifications, including 110 kW charging capacity, 225 kWh of usable storage capacity, and a highly efficient liquid cooling system, already indicate its enormous potential. Flexible in terms of installation location and application area, it also offers reliable operation thanks to a three-stage safety concept. The multi-cascadable system is ideal for small and large commercial applications.
Product advantages:
• Ideal for a wide range of C&I applications
• Multiple cascadable configurations
• 3-stage fire protection concept
• Efficient liquid cooling system
• On-site commissioning support included
Product features:
• AC power: 110.0 kW
• AC connection: 400 V, 3-phase
• Battery capacity (usable): 229.0 kWh
• Cell chemistry: LFP
• Communication: Ethernet
• Protection class: IP55
• Cooling: Intelligent liquid cooling
• Dimensions: 2450 x 1150 x 1610 mm (HxWxD)
• Total weight: 3100.0 kg
Smart meters compatible with the EMS300CP (CTs can be added as needed):
- DTSD1352, 6A (item 0150242)
- DTSU666-20 (item 0154200)
- Janitza UMG 604/104
- Janitza UMG 96-PQ-L
- Weidmüller EM610
Conclusion:
Its performance and capacity make it the ideal system component for many C&I applications.
Wichtige technische Daten
| Dangerous goods transportation category | 2 |
|---|---|
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Dangerous goods class | 9 |
| Dangerous goods Weight (net) (kg) | 1648.000 |
| Dangerous goods description | LITHIUM ION BATTERIES CONTAINED IN EQUIPMENT |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
Technical details
| Max. C-rate | 3.00 |
|---|---|
| Battery voltage | High Voltage |
| Battery cell chemistry | LFP |
| Nominal voltage DC (V) | 400.00 |
| Min. temperature ambient (°C) | -30 |
| Protection degree | IP55 |
| Usable capacity (kWh) | 225.00 |
| Intrastat country of origin | China |
|---|---|
| Dangerous goods transportation category | 2 |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Manufacturer item name | ST225kWh-110kW-2h |
| Intrastat product number (HS-code) | 85076000 |
| Manufacturer | Sungrow |
| Dangerous goods class | 9 |
| Dangerous goods Weight (net) (kg) | 1648.000 |
| Dangerous goods description | LITHIUM ION BATTERIES CONTAINED IN EQUIPMENT |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
| Width incl. packaging (cm) | 115.00 |
|---|---|
| Weight incl. packaging (Kg) | 2930.000 |
| Amount per Pallet | 1 |
| Pal. dim. LxBxH (mm) | 1195x1700x2500 |
| Pal. weight (kg) | 2930.00 |
| Height incl. packaging (cm) | 245.00 |
| Length incl. packaging (cm) | 161.00 |
| Length without packaging (mm) | 1610.00 |
|---|---|
| Width without packaging (mm) | 1150.00 |
| Weight without packaging (kg) | 2895.000 |
| Height without packaging (mm) | 2450.00 |
