Power Optimizer M600-E
Product information "Power Optimizer M600-E"
Please check the system planning directly with the BRC Solar inverter checker. The installation technician is always responsible for checking and documenting the system design.
The M600-E Power Optimizer from BRC permanently maximises the performance of PV systems by compensating for typical yield losses caused by shading, different module orientations, or tilt angles. This improves the performance of your PV system and allows you to install and use more PV modules. The optimiser is equipped with a standby function and ultra-fast MPP tracking, switching 20 times faster. Thanks to the sophisticated plug-and-play system, installation is particularly easy and requires no additional software or app. The M600-E is compatible with the most common inverters, offering maximum flexibility. It is ideal for both new installations and retrofits. Manufactured with durable, long-life electronics, the optimiser impresses with its high reliability and a 25-year warranty.
Product advantages:
• Increases energy yields through intelligent optimisation
• Standby function and ultra-fast MPP tracking
• Easy installation thanks to plug-and-play system
• Compatible with most common inverters
• High reliability backed by a 25-year warranty
Product features:
• Rated input power: 600 W
• Short circuit current Isc: 20 A
• MPP max. voltage range input: 70 V
• MPP min. voltage range input: 16 V
• Max. input voltage DC: 70 V
• Interface: Powerline
• DC connector type: MC4
• Cable length output: 120 cm (plus) / 120 cm (minus)
• Weight: 0.42 kg
• Warranty: 25 years
Technical details
| DC connector type | MC4 |
|---|---|
| Length of cable output plus (cm) | 120.00 |
| Short circuit current Isc (A) | 20.00 |
| Max. input voltage DC (V) | 70.00 |
| MPP min. voltage range input (V) | 16.00 |
| Protection degree | IP68 |
| Rated input power (W) | 600 |
| MPP max. voltage range input (V) | 70.00 |
| Length of cable output minus (cm) | 120.00 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer | BRC Solar |
| Manufacturer item name | POWER OPTIMIZER M600-E |
| Intrastat product number (HS-code) | 90328900 |
| Weight incl. packaging (Kg) | 0.600 |
|---|---|
| Amount per Pallet | 792 |
| Height incl. packaging (cm) | 2.20 |
| Pack. material | cardboard box |
| Amount per big Box | 22 |
| Width incl. packaging (cm) | 7.80 |
| Length incl. packaging (cm) | 14.50 |
| Width without packaging (mm) | 78.00 |
|---|---|
| Length without packaging (mm) | 145.00 |
| Height without packaging (mm) | 22.00 |
| Weight without packaging (kg) | 0.420 |
