Home Manager 2.0
Energy management, 1/3-phase, direct up to 63A
Art-No.
0126650
Manufacturer No.
HM-20
Product details
Product information "Home Manager 2.0"
For currents >63 A, suitable measuring transformers must be added.
The SMA Home Manager 2.0 is the control center for intelligent energy management in the home. In addition to recording all energy flows, generation and surpluses, it regulates their best possible distribution. Thanks to local weather forecasts, storage and direct use are optimally coordinated via controllable consumers. The self-learning device creates individual consumption profiles and thus ensures the most efficient use of self-generated PV energy. Dynamic electricity tariffs can also be used with the Home Manager.
Product benefits:
• Energy manager with integrated measuring device
• Optimized storage charging incl. weather forecast
• Use of dynamic electricity tariffs
• Control of intelligent consumers
Product features:
• Measuring direction: bidirectional
• Input current: <63 A direct (>63 A indirect with additional CTs)
• Mains connection: 230 / 400 V
• Connection phases: 1 / 3
• Communication: Ethernet
• Mounting: top-hat rail
• Protection class: IP2X
• Dimensions: 70 (4 HP) x 88 x 65 mm (L x W x H)
• Weight: 0.3 kg
Technical details
| Display | w/o display |
|---|
| Intrastat country of origin | Germany |
|---|---|
| Manufacturer | SMA |
| Manufacturer item name | Sunny Home Manager 2.0 |
| Intrastat product number (HS-code) | 90328900 |
| Weight incl. packaging (Kg) | 0.400 |
|---|---|
| Width incl. packaging (cm) | 16.00 |
| Amount per big Box | 1 |
| Height incl. packaging (cm) | 10.00 |
| Length incl. packaging (cm) | 11.00 |
| Width without packaging (mm) | 70.00 |
|---|---|
| Weight without packaging (kg) | 0.300 |
| Height without packaging (mm) | 65.00 |
| Length without packaging (mm) | 88.00 |
