sonnenBatterie 10 performance, 10p/44
Set
1x
sonnenBatterie 10 performance Inverter
sonnen
0153112
2x
sonnenBatterie 10 performance / + system cabinet
sonnen
0133005
2x
sonnenBatterie 10 performance Accessory-Kit
sonnen
0153785
8x
sonnenBatterie 10 performance+, 5,5 kWh S1
sonnen
0163856
1x
sonnenBatterie 10 performance / + Expansion-Kit
sonnen
0133008
AC storage system, 19.80 kW, 40 kWh usable, 3-ph
Art-No.
0163898
Product details
Product information "sonnenBatterie 10 performance, 10p/44"
Only for AT.
The system's total weight is distributed proportionally between the wall mounting and the feet. Sufficient load-bearing capacity of the masonry must be ensured on-site.
The system's total weight is distributed proportionally between the wall mounting and the feet. Sufficient load-bearing capacity of the masonry must be ensured on-site.
For more than four storage modules, a second enclosure and the expansion kit are required. Battery modules can only be installed and expanded in pairs.
For backup functionality, including integration of a PV inverter*, the sonnenProtect 8000 Box is also required.
The Sonnen performance system is the smart energy control center for home energy storage applications. It can be flexibly combined with new or existing PV systems and, optionally, with the sonnenProtect 8000 Box, can also be used for backup power*. The usable storage capacity ranges from 10 to 50 kWh and can be expanded indefinitely. The system can be cascaded up to nine times, making it suitable for larger applications as well. Quality Made in Germany.
Product advantages:
• Flexible AC storage system
• Optional sonnenProtect 8000 Box* for backup power and solar recharging
• System can be cascaded up to 9 times
System specifications:
• AC nominal power: 19.80 kW
• Feed-in phases: 3
• AC grid voltage: 400 V
• Battery capacity (usable): 40.0 kWh
• Expansion time window: unlimited
• Number of storage modules in one system: 2 to 10
• Cell chemistry: LFP
• Communication: LAN, RS485, RSD, DI, DO
• Cooling: active
• Protection class: IP30
• Number of enclosures: 2
• Dimensions: 2 x 1720-1840 / 690 / 360 mm
• Weight: 456.0 kg
• Warranty: 10 years (after online registration)
*AC installation according to the instructions for solar recharging; the PV inverter must be connected via AC frequency controllable
Scope of delivery:
- 1 x Sonnen sonnenBatterie 10 performance Power Unit S1, System Inverter (Item 0153112)
- 2 x Sonnen sonnenBatterie 10 performance System Housings (Item 0133005)
- 8 x Sonnen sonnenBatterie 10 performance Storage Modules (Item 0163856)
- 2 x Sonnen sonnenBatterie 10 performance Accessory Kits (Item 0153785)
- 1 x Sonnen sonnenBatterie 10 performance Extension Kit (Item 0133008)
Wichtige technische Daten
| Dangerous goods transportation category | 2 |
|---|---|
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| Dangerous goods Weight (net) (kg) | 490.000 |
| UN No. | 3480 |
Downloads
- Further Information German
- Mounting Instructions German
- Warranty Terms German
- Datasheet German
- Declaration of Conformity German
- Operationsmanual German
-
sonnenBatterie 10 performance Accessory-Kit0153785
Technical details
| Topology | transformerless |
|---|---|
| Discharging power (kW) | 19.80 |
| Protection degree | IP30 |
| Max. AC power (kVA) | 19.80 |
| Backup system full | yes with supply |
| Usable capacity (kWh) | 40.00 |
| Max. nominal charging power (kW) | 19.80 |
| Min. temperature ambient (°C) | -5 |
| AC nominal power (kW) | 19.80 |
| Feed-in phases | 3 |
| Battery Connection | AC |
| Surge protection AC | no |
| Display | w/o display |
| Battery voltage | High Voltage |
| Battery cell chemistry | LFP |
| Max. discharging power (kW) | 19.80 |
| Charging power (kW) | 19.80 |
| Amount connected phases | 3 |
| Integrated DC switch | no |
| Intrastat country of origin | China |
|---|---|
| Dangerous goods transportation category | 2 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Intrastat product number (HS-code) | 85076000 |
| Dangerous goods class | 9 |
| Manufacturer | sonnen |
| Dangerous goods packaging type | 4G |
| Dangerous goods Weight (net) (kg) | 490.000 |
| UN No. | 3480 |
| Weight incl. packaging (Kg) | 467.400 |
|---|
| Weight without packaging (kg) | 456.000 |
|---|
| Warranty provider | sonnen |
|---|
