GW112.6-BAT-AC-G10 + GW100K-ET-G10
HV storage system, 110.0 kWh usable, 3-phase
Art-No.
0163547
Product details
Product information "GW112.6-BAT-AC-G10 + GW100K-ET-G10"
Scope of delivery:
• Goodwe GW100K-ET-G10 Hybrid inverter (item 0163065)
• Goodwe GW112.6-BAT-AC-G10 Commercial storage (item 0161781)
Wichtige technische Daten
| Dangerous goods Weight (net) (kg) | 990.000 |
|---|---|
| Dangerous goods transportation category | 2 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
Downloads
-
GW112.6-BAT-AC-G100161781
-
GW100K-ET-G100163065
-
GW112.6-BAT-AC-G100161781
-
GW100K-ET-G100163065
Technical details
| Topology | transformerless |
|---|---|
| Max. AC power (kVA) | 110.00 |
| Max. generator power DC (kWp) | 200.00 |
| Backup system full | yes with supply |
| Start input voltage (V) | 200 |
| Number of independent MPPT (pcs) | 8 |
| Max. short circuit current (A) total | 440.00 |
| Max. input voltage DC (V) | 1000.00 |
| Max. output current (A) | 167.20 |
| Surge protection AC | type 2 |
| European efficiency (%) | 97.50 |
| MPP max. voltage range input (V) | 950.00 |
| Capacity extendable later | yes without restriction |
| Commercial system | yes |
| Display | w/o display |
| Min. temperature ambient (°C) | -20 |
| Battery cell chemistry | LFP |
| MPP min. voltage range input (V) | 160.00 |
| AC nominal power (kW) | 100.00 |
| Max. efficiency (%) | 98.10 |
| Integrated DC switch | yes |
| Total number of string inputs | 16 |
| Max. input current DC (A) total | 336.00 |
| Protection degree | IP55 |
| Usable capacity (kWh) | 110.00 |
| Max. short circuit current per MPPT (A) | 55 |
| Arc Fault Circuit Interrupter | yes |
| Max. input current per MPPT (A). | 42 |
| Surge protection DC | type 1 and type 2 |
| Intrastat country of origin | China |
|---|---|
| Dangerous goods Weight (net) (kg) | 990.000 |
| Dangerous goods transportation category | 2 |
| Dangerous goods description | LITHIUM ION BATTERIES |
| Tunnel restriction code | (E) |
| Classification code | M4 |
| Manufacturer | GoodWe |
| Intrastat product number (HS-code) | 85076000 |
| Dangerous goods class | 9 |
| Dangerous goods packaging type | 4G |
| UN No. | 3480 |
| Manufacturer item name | BAH112K-06-00P*GW100K-ET-G10 |
| Weight incl. packaging (Kg) | 1584.300 |
|---|
| Weight without packaging (kg) | 1497.000 |
|---|
