BMS-PARALLEL BOX-II-G2
with 1st cable set for T30 memory
Art-No.
0155967
Manufacturer No.
106015000000
Product details
Product information "BMS-PARALLEL BOX-II-G2"
This box is only designed for use with the Solax T30 battery. An additional cable set is required to connect a second battery tower.
The 2nd generation of the BMS parallel box enables the connection of two battery strings of the same length in order to maximize the storage capacity per inverter. In addition, the two battery connections were designed to expand existing systems. The already installed storage can continue to be operated including the BMS at the main input. The new battery modules are connected to the slave input without an external BMS. This results in the best possible cost-benefit ratio. Both battery groups are operated independently of each other by the BMS parallel box and offer a high level of reliability in the event of a battery fault.
• Compatible batteries: T-BAT-H T3.0
• Included connection cable to the memory: T-BAT-H T3.0
• Compatible inverters: X1/3-Hybrid G3 and X1/3-Hybrid G4
Details on connecting the different battery types can be found in the instructions.
Number of memories X1-Hybrid:
• 1x1, 1x2, 1x3 batteries
• 2x1, 2x2, 2x3 batteries
Number of memory X3-Hybrid / X3-Ultra:
• 1x2, 1x3, 1x4 batteries
• 2x2, 2x3, 2x4 batteries
Technical details
| Nominal current (A) | 25.00 |
|---|---|
| Protection degree | IP65 |
| Min. temperature ambient (°C) | -10 |
| Battery voltage | High Voltage |
| Number battery connections | 2 |
| Number inverter connections | 1 |
| Surge protection DC | type 2 |
| Max. input voltage DC (V) | 550.00 |
| Intrastat country of origin | China |
|---|---|
| Manufacturer | SolaX Power |
| Intrastat product number (HS-code) | 85079080 |
| Manufacturer item name | BMS-PARALLEL BOX-II G2 |
| Weight incl. packaging (Kg) | 10.000 |
|---|---|
| Pack. material | cardboard box |
| Amount per Pallet | 42 |
| Height without packaging (mm) | 154.00 |
|---|---|
| Width without packaging (mm) | 334.00 |
| Length without packaging (mm) | 368.00 |
| Weight without packaging (kg) | 8.700 |
| Product warranty (yr) | 2 |
|---|---|
| Standard product warranty (yr) | 2 |
| Warranty provider | SolaX Power |
